RELIANCE Monopoly Design: Advanced ABC Powder Fire Fighting Systems
High-Performance 150 KG ABC Fire Extinguishing Unit
The RELIANCE 150 KG ABC Powder Fire Fighting Unit is a state-of-the-art, heavy-duty fire suppression system designed for maximum safety and rapid response. Engineered to comply with OISD (Oil Industry Safety Directorate) norms, this unit is suitable for all classes of fires, including A, B, C, and electrical types.
Built to Last: Robust Construction and Design Standards :
- Tank Material: Constructed using boiler-grade steel plates with 8 mm thickness for long-lasting durability.
- Welding Standard: Radiographic welding in accordance with ASME code ensures structural integrity under high-pressure conditions.
- Mounting: The unit is trolley-mounted, allowing for ease of movement and transport in industrial or on-site environments.
Fire Suppression Performance Features :
Precision Nozzle and Hose System
Equipped with a 15-meter hose reel.
Features a pistol-type discharge nozzle (AK-47 Model) for controlled targeting of flames.
Superior Diffuser Technology :
Utilizes a proprietary diffuser system, ensuring a minimum discharge efficiency of 98%.
Capable of a discharge throw range of 28 to 30 meters, making it ideal for large-area coverage.
Operational Flexibility
Fully regulatable operation, allowing the user to control pressure and output as needed.
Low maintenance system, designed for long-term usage with minimal upkeep.
All-Weather Capability and Mobility
Specially engineered to be weather-resistant, offering protection from sun and rain.
Available as both: Trailer-mounted for easy towing.
Vehicle-mounted on self-driven chassis (e.g., Mahindra or equivalent), making it ideal for mobile fire control in remote or expansive industrial zones.
AUTO ABC 150KG Fire Extinguishing System with Intelligent Detection
Next-Gen Fire Safety: Auto Fire Detection Tube Technology
The RELIANCE Skid-Mounted 150 KG ABC Powder Unit with Auto Fire Detection Technology represents the future of fire prevention. Designed for environments where immediate automated response is crucial, this system ensures rapid detection and suppression without human intervention.
Key System Components and Operation
Skid-mounted frame housing an ABC container and expelling CO₂ cylinder.
Equipped with a 25-meter-long auto fire detection tube, sensitive to temperature spikes.
Fitted with an imported Ceodeux valve and high-efficiency diffuser for rapid discharge.
The fire detection tube is pressurized at 12 kg/cm² and ruptures at 115°C, triggering the expelling mechanism.
Upon rupture, pressure drops to zero, automatically activating the valve, releasing CO₂ to discharge the ABC powder through a manifold and diffuser system.
Rupture disc included in the main cylinder, engineered for optimal discharge pressure, and can be tailored to specific hazardous environments.
Benefits of Automatic Fire Detection Systems
24/7 autonomous operation without manual input. Instantaneous response to emerging fires, ideal for unmanned or high-risk industrial zones.
Highly customizable for different fire hazard zones, especially for flammable material storage or processing plants.
Why Choose RELIANCE Fire Suppression Systems?
Compliant with international fire safety standards
- Proven 98–99% discharge efficiency
- Long-range fire suppression (up to 30 meters)
- Custom mounting options for fixed or mobile use
- Designed for all fire classes (A, B, C & Electrical).
